- Description
AISTAR Controls M and MA Series rotary motion positive displacement (PD) meters offer the ultimate in measurement accuracy for custody transfer of petroleum products, aviation fuels, LPG, and a broad range of industrial liquids
Superior performance features
Low pressure drop - will operate on gravity flow or pump pressure.
Sustained accuracy - no metal-to-metal contact inside the measuring chamber means minimal wear and deterioration in accuracy over time, fewer calibration, and longer service life. Meters conform to NIST and International Weights and Measures accuracy requirements.
Wide viscosity range - LC meters can accurately meter products from less than 30 SSU (less than 1 centipede) to 1,500,000 SSU (325,000 )Centipede.
Maximum adaptability - choice of stock or custom elbows/fittings provides unequaled mounting flexibility to meet widely varying installation requirements.
Accuracy/Performance*
Repeatably Capable of 0.02% or better at any flow rate over entire range
Linearity
Over 5:1 range Mech. registration: capable of ± 0.125% or better from max. nom. flow rate
Elect. registration: capable of ±0.10% or better from max. nom. flow rate
Over 10:1 range Mech. registration: capable of ±0.22% or better from max. nom. flow rate
Elect. registration: capable of ± 0.10% or better from max. nom. flow rate
Over 40:1 range Mech. registration: capable of ±0.5% or better from max. nom. flow rate
Elect. registration: capable of ±0.15% or better from max. nom. flow rate
Temperature range -40° F to 160° F (-40° C to 71° C)
*Stated accuracy obtainable when all variables remain constant. Reading/measurements
reflect a minimum of one minute of flow at selected rate(s). All accuracy statements
based on metering safety solvent (aliphatic hydrocarbon), approximate viscosity 1 CPS.
On higher viscosity products, the average deviation in accuracy will be less.
Construction
Meter housing and rotors
Cast aluminum or
stainless steel
Internal components
Aluminum, Ni-Resist,
stainless steel
Bearings
Carbon, Teflon, Ni-Resist
Vi ton and Teflon are
registered trademarks of
DuPont Corporation
Industries served
LC M and MA series
meters are well suited for
use in industries requiring
precise flow
measurement and
reliable, extended service
life:
• Refined petroleum
products
• Aviation fuels
• LPG
• Agricultural chemicals
• Paints and coatings
• Foods and beverages
• Petrochemicals
• Pharmaceuticals
• Cosmetics
• Printing Inks
• Textiles
Superior performance features
Low pressure drop - will operate on gravity flow or pump pressure.
Sustained accuracy - no metal-to-metal contact inside the measuring chamber means minimal wear and deterioration in accuracy over time, fewer calibration, and longer service life. Meters conform to NIST and International Weights and Measures accuracy requirements.
Wide viscosity range - LC meters can accurately meter products from less than 30 SSU (less than 1 centipede) to 1,500,000 SSU (325,000 )Centipede.
Maximum adaptability - choice of stock or custom elbows/fittings provides unequaled mounting flexibility to meet widely varying installation requirements.
Accuracy/Performance*
Repeatably Capable of 0.02% or better at any flow rate over entire range
Linearity
Over 5:1 range Mech. registration: capable of ± 0.125% or better from max. nom. flow rate
Elect. registration: capable of ±0.10% or better from max. nom. flow rate
Over 10:1 range Mech. registration: capable of ±0.22% or better from max. nom. flow rate
Elect. registration: capable of ± 0.10% or better from max. nom. flow rate
Over 40:1 range Mech. registration: capable of ±0.5% or better from max. nom. flow rate
Elect. registration: capable of ±0.15% or better from max. nom. flow rate
Temperature range -40° F to 160° F (-40° C to 71° C)
*Stated accuracy obtainable when all variables remain constant. Reading/measurements
reflect a minimum of one minute of flow at selected rate(s). All accuracy statements
based on metering safety solvent (aliphatic hydrocarbon), approximate viscosity 1 CPS.
On higher viscosity products, the average deviation in accuracy will be less.
Construction
Meter housing and rotors
Cast aluminum or
stainless steel
Internal components
Aluminum, Ni-Resist,
stainless steel
Bearings
Carbon, Teflon, Ni-Resist
Vi ton and Teflon are
registered trademarks of
DuPont Corporation
Industries served
LC M and MA series
meters are well suited for
use in industries requiring
precise flow
measurement and
reliable, extended service
life:
• Refined petroleum
products
• Aviation fuels
• LPG
• Agricultural chemicals
• Paints and coatings
• Foods and beverages
• Petrochemicals
• Pharmaceuticals
• Cosmetics
• Printing Inks
• Textiles
