- Description
12V/24V DC fuel pump
- Durable cast iron pump housing built to withstand the wear and tear of rough operating environments
- Comes with a 3/4" x 12' discharge hose, 3/4" manual nozzle, 18' 12 gauge power cord with clips, and 1" x 34" telescoping steel suction pipe
- 1/4 hp DC motor @ 2,600 RPM provides up to 37' of discharge head
- 20 amp draw (maximum) with a 30 minute duty cycle
- 1" Inlet, 3/4" Outlet, and 2" Bung Mount with NPT threads
Product Specifications
| Part Number | FR1210G |
|---|---|
| Number of Items | 1 |
| Maximum Pressure | 1.103 bars |
| Specification Met | UL |
| UPC | 640026847342 , 089404207932 , 640024792101 , 089404223079 , 636123678736 |
| Color | RED |
| EAN | 0636123678736 , 0640024792101 , 0640026847342 , 0089404223079 , 0089404207932 |
| For use with what product? | Gasoline, Diesel, Kerosene, Ethanol Blends to 15%, Methanol Blends to 15%, Bio-Diesel to B20 |
| Included Components | 3/4" x 12' discharge hose, 3/4" manual nozzle, 18' 12 gauge power cord with clips, 1" x 34" telescoping steel suction pipe |
| Inlet Connection Size | 1 inches |
| Inlet Connection Type | Female NPT Threads |
| Is Assembly Required? | false |
| Item Weight | 35.0 pounds |
Description
- Brand new and high quality
- Ball Bearing Construction, No Lubrication Required
- Thermally protected and explosion-proof
- Cast Iron material pump body
- Manual Nozzle
- 2" Male NPT On Bung Adapter
- 1" Female NPT On Suction Port
Specifications
- Color: Blue
- HP: 1/4
- AMP: 22
- Watts: 264
- Flow (GPM): 20
- RPM Speed: 2600
- Max. Total Head : 36.96 ft
- Max. Suction Lift : 8 ft
- Inlet Port: 1"
- Outlet Port : 1"
- Duty Cycle: 30 Min.
- Seal Type: Oil Seal
- Nose: 3/4" x 12ft
